Magnetic Buzzer 12x9.5mm 5V DC 85db with Pin
Magnetic Buzzer self-drive type, also known as indicators, are designed with an internal drive circuit for easy application integration. During operation, current is driven through a voice coil to produce a magnetic field. When a voltage is applied, the coil generates a magnetic field and then allows the diaphragm to vibrate and produce sound. This buzzer type has a low operating voltage ranging from 1.5 – 12V+. Our magnetic buzzers are desirable for applications requiring a lower sound pressure level (SPL) and frequency.
Our products are widely used in home appliances, cordless phones, medical devices, electric bicycles, cars, computers, alarm systems. From product designing, purchasing and testing, every step is controlled strictly by our QC staffs in order to make sure the perfect quality of our products.
The company is a reliable, well-developed and professional manufacturer of electronic acoustic products, providing electromagnetic buzzer, SMD Piezo Buzzer, Speaker, Mylar Speaker, Mechanical Buzzer, alarms and so on.
The management philosophy of our company are integrity, responsibility, cooperation, innovation and development since the establishment of the company. We guarantee our customers the best quality products, competitive price, and fast delivery.
With professional skills, enthusiasm and ambition, we are looking forward to corporate with you. Welcome to Huawha!
Specification
| Type | Spec |
| 1 | Rated voltage | 5.0VDC |
| 2 | Operation voltage | 3~8VDC |
| 3 | Sound Pressure Level=SPL | Min 85dB |
| 4 | current | Max 30mA |
| 5 | Oscillation frequency | 2300±300Hz |
| 6 | Operating Temperature | -20～+70℃ |
| 7 | Storage temperature | -30～+85℃ |
| 8 | Externals size （mm） | Φ12*H9.5 |
| 9 | Mass | 2g |
| 10 | Housing Material | PPO |
| 11 | Envionmental Protection Regulation
| RoHS |
Dimension
Frequency Curve
Looking for ideal Diameter 12mm Height 9.5mm Magnetic Buzzer Manufacturer & supplier ? We have a wide selection at great prices to help you get creative. All the Soler Energy Thermometer Buzzer are quality guaranteed. We are China Origin Factory of 5V DC 2300Hz Magnetic Buzzer. If you have any question, please feel free to contact us.
Product Categories : Buzzer > Magnetic Buzzer Self-drive Type
